Acrylic Screen Tube

Product Tabs

Product Details

Screen tubes are used in hollow base material applications to contain adhesive around the anchor and prevent it from running into voids, such as hollow block and brick. Simpson Strong-Tie® screen tubes are specifically designed to work with AT-HP Blue and SET-XP adhesives in order to precisely control the amount of adhesive that passes through the mesh. This results in thorough coating and bonding of the rod to the screen tube and base material.

Material

Polypropylene

Features & Benefits
  • Integral Cap: Secures the rod in tube. Displays rod diameter, drill bit diameter and the Simpson Strong‑Tie® "≠" sign for easy inspection. Prevents adhesive from running out of the front of the screen tube
  • Flange: Prevents the screen tube from slipping into over-drilled holes
  • Colour-Coded, Formula-Specific Mesh: The screen tube mesh is sized to allow only the right amount of adhesive to flow through the screen tube to bond with the base material while the balance remains in the screen to bond the rod
Applications
  • Hollow brick and masonry adhesive anchoring
Model No. Table

Model No.

Description

Size

Box Qty

SH12050-RP10

Suits M8 diameter rod

12mm x 50mm

10

SH16085-RP6

Suits M8–M10 diameter rod

16mm x 85mm

6

SH16130-RP6

Suits M8–M10 diameter rod

16mm x 130mm

6

SH20085-RP4

Suits M12–M16 diameter rod

16mm x 130mm

6
