"Say goodbye to visible nails and screws!"

The MT Merbau/Kwila Clip is specifically designed for 90mm kiln-dried Merbau/Kwila decking. Due to potential differences in shrinkage rates and hardness, it is not recommended for use with other hardwood or softwood timber species. This concealed fixing system delivers an aesthetically pleasing deck, free from the visual distraction of top-fixed screws or nails.

This versatile system is compatible with a range of joist materials, including timber (such as treated pine and kiln-dried hardwood) and steel (like metal RHS joists and C purlins). We advise checking with the supplier to confirm suitability when using LVL joists, and recommend avoiding unseasoned hardwood joists and ensuring all timber is seasoned to in-service moisture levels to avoid shrinkage related issues.

Material & Finish
  • MT90G - Z275 Galvanised
  • MT90S - 304 Stainless Steel
Features & Benefits
  • Achieve an aesthetically pleasing deck without the detraction of top-fixed screws and nails.
  • Quick and easy-to-use system that reduces labour during installation.
  • Prevents water damage to boards by eliminating exposed screw and nail holes.
  • Maintains consistent spacing between boards for a uniform finish.
  • No top-fixing allows deck boards to be easily re-sanded when needed.
  • Suitable to be used in bushfire prone areas up to a rating of BAL-29 as per AS3959:2018.
Approvals
  • Suitable to be used in bushfire prone areas up to a rating of BAL-29 as per AS3959:2018.
Model No. Table

Specifications - MT Merbau / Kwila Clip

Model No.

Dimension

Size (mm)

Material & Finish

Box Qty

MT90G

Suitable for 90mm Kiln Dried Merbau/Kwila

555 x 60

Carbon Steel, Z275 Galvanised

40

MT90S

304 Stainless Steel



Note: A fixing tool is included in every box of clips.

Brochures & Catalogues

Brochures and Catalogues

PDF icon Flyer - MT Merbau / Kwila Clip
Technical Data & Docs

Warranty

Warranty

Masterspec
Alternative Products

Alternative Products

The DSD hardwood decking screw has been developed to install without the need to pre‑drill boards. With toughened 316 stainless steel and coarse threads, it will fasten most species of hardwood.

DHSD_Decking Screw_Hardwood-to-Hardwood - Loose

The DHSD Hardwood-to-Hardwood screw is ideal for hardwood decking applications and is specifically designed to penetrate the hardest timber with ease. The unique Drill Point virtually eliminates splitting without the need of pre-drilling.

The DHW is a premium decking fastener designed for no predrilling in hardwood decking applications. The winged design and hardwood drill point virtually eliminates splitting of timber without predrilling in the hardest timber applications.
